Product Description

Polypropylene ( PP ) Air-operated Fulid Oil Transfer Drum Pump


Materials: PP


Pipe Qty: 1 Piece


Suction Tube Length: 98CM


Overall Length: 130CM


Inlet/Outlet Dia: 43mm/22mm


Flow Rate: 190ML/Stroke


Max Flow GPM: 8(water)


Max Pressure: 100PSI


Specification:Fits 5 to 55 gallon drums


Application(s): For AdBlue/DEF, water, alcohol, gasoline, diesel, kerosene, lubricant, water based chemical acid and alkali solutions

 0512.jpg Plastic PP Air-operated Drum Pump
Model Foot Press Fluid Transfer Pump
Pump Construction PP
Tube Material PP
Tube Nos 1PC
Inlet Tube Length 98CM
Overall Length 130CM
Inelt Dia 43mm
Outlet Dia 22mm
Flow Rate 190ML/Stroke
Max Flow GPM 8(water)
Max Pressure 100PSI
Applicable Drums Fits 5 to 55 gallon drums
Applications AdBlue/DEF, water, alcohol, gasoline, diesel, kerosene, lubricant, water based chemical acid and alkali solutions

9L Manual Oil Extractor 9L Manual Fluid Gear Engine Oil Extractor Pump Bleeder
Capacity 9L Manual Operation Oil Fluid Extractor
Material PP
Weight 3KG
Size 35 x 30 x 70cm
Brass Hose Dia x 1  6mm
Plastic Hose Dia x 3 4mm/8mm/10mm
Air Inlet 1/4"
Working Pressure 0~170 PSI / 0~11.9 BAR
Package 1UNIT/BOX,2PCS/CTN
Package size 58 x 31 x 64cm
NW / GW 9Kg/10Kg
Applications All engine, transmission and lubricating oils

Foot Pump Plastic PP Oil Delivery Pump Foot Press Type
Model Foot Press Fluid Transfer Pump
Pump Construction PP
Nozzle  pp
Inlet/Outlet Hose PVC stainless steel wire inlet hose
Inlet Hose Length 2m
Outlet Hose length 2m
Inelt/Outlet Dia 19mm
Sealing EPDM
Spring Stainless steel
Flow Rate 400ML/Press
Applications Adblue/Def solutions,water,alcohol,kerosene,lubricant,water based chemical solutions

Jiggle Siphon Self Priming Shaker Siphon Hose Brass Jiggler Pump
Model GT-125 Shaker Siphon Hose Jiggler Pump
Materials PVC anti-static fuel hose
Hose Color Transparent light blue
Hose Dia 16mm
Hose Thickness 1.8-2mm
Pump Head Copper with glass ball
Overall Length 183cm
Net Weight 290g
Flow Rate 14L/Minute
Applications Water,antifreeze,diesel,kerosene and
non-corrosive liquids
Packing 3 Zip Ties

Rubber Ball Siphon Pump 180CM Rubber Ball Siphon Pump Syphon Hose
Model GT-124 Rubber Ball Siphon Pump
Materials PVC Hose + Rubber Ball
Inlet Dia 6.5mm
Outlet Dia 8mm
Length 180cm
Net Weight 85g
Flow Rate 2.5L/Minute
Applications Oils,gasoline,diesel,water.fluids and antifreeze
transferring
Packing Blister Card

GT-127 Siphon Pump Car Siphon Pump Gas Oil Water Transfer Sucker
Art No  DP-14 / GT127
Material PE
Self-Priming Yes
Inlet/Outlet Dia 17mm/17mm
Suction 400mm
Lift 450mm
Capacity 7-9L/Min
Length 640mm
Packing 120PCS/CTN
G.W/N.W 9/7KGS
Measurement 59x55x51mm
Applications Chemicals,petroleum based fluids,water

GT-128 Siphon Pump Liquid Fuel Transfer Plastic Siphon Pump
Art No.  DP-22 / GT128
Material PE
Self-Priming Yes
Inlet/Outlet Dia 22mm/22mm
Suction 850mm
Lift 1400mm
Capacity 13-15L/Min
Length 1080mm
Packing 36PCS/CTN
G.W/N.W 11.5/9.5KGS
Measurement 113 x 45 x 34mm
Applications Chemicals,petroleum based fluids,water

GT-129 Siphon Pump Siphon Pump Fuel Gas Liquid Water Transfer Dispenser
Art No.  DP-25 / GT129
Material PE
Self-Priming Yes
Inlet/Outlet Dia 25mm/25mm
Suction 850mm
Lift 1200mm
Capacity 16-18L/Min
Length 1160mm
Packing 36PCS/CTN
G.W/N.W 13/11KGS
Measurement 118 x 49 x 40mm
Applications Chemicals,petroleum based fluids,water

 GT-123 5 Gallon PVC/Nylon Hand Pail Pump Vertical Lift Pump
Model GT-123 PVC/Nylon Hand Pail Pump
Inlet Dia 34mm
Outlet Dia 16mm
Suction Head 56cm
Pump Head 50cm
Flow Rate 200ML/Stroke
Pump Construction PVC
Inlet Pipe  PVC
Seals PTFE
Adaptor Universal adaptor
Drums 5 Gallon
Net Weight 0.34kgs
Additional A hose barb and 3/4"NPT threads at pump bottom
Applications Hydraulic fluid,transmission fluid,motor oil

GT149 Lever Hand Pump P-490 Plastic Lever Drum Pump Viton Seals
Art No.  P-490 / GT149
 Material PP + 201SS
Seal Material Viton
Shrank ABS
Inlet / Outlet Dia  37mm / 22mm
Product Length 1370mm
Speed 55 Stroke / Min
Capacity 320-350cc/Stroke
Flowing 19L/Min
Suction / Lift 1m /0. 5m
Applicable Drums 15 - 55 Gallon
Packing 1PC/BOX,6PCS/CTN
N/G Weight 5.1/6.5KGS
Carton Size 38.5 x 32 x 28.5cm

GT150 Lever Hand Pump P-490S Polypropylene Lever Action Barrel Pump
Art No.  P-490S / GT150
 Material Strengthen PP + 304SS
Seal Material Viton
Shrank ABS
Inlet / Outlet Dia  37mm / 22mm
Product Length 1370mm
Speed 55 Stroke / Min
Capacity 320-350cc/Stroke
Flowing 19L/Min
Suction / Lift 1m /0. 5m
Applicable Drums 15 - 55 Gallon
Packing 1PC/BOX,6PCS/CTN
N/G Weight 5.4/6.7KGS
Carton Size 38.5 x 32 x 28.5cm
Applications Diesel,kerosene,engine oil,water, adblue, weak acid

GT151 Lever Hand Pump R-490S Lever Action Drum Pump with Ryton Body
Art No. R-490S / GT151
Material  PPS + 316SS
Seal Material Viton
Shrank ABS
Outlet Tube PP
Inlet / Outlet Dia  37mm / 22mm
Product Length 1370mm
Speed 55 Stroke / Min
Capacity 320-350cc/Stroke
Flowing 19L/Min
Suction / Lift 1m /0. 5m
Applicable Drums 15 - 55 Gallon
Packing 1PC/BOX,6PCS/CTN
N/G Weight 7.5/8.8KGS
Carton Size 38.5 x 32 x 28.5cm
Applications Diesel,kerosene,engine oil,water, adblue, weak acid

 GT146 Rotary Barrel Pump RP-90P Polypropylene Rotary Barrel Pump Def Compatible
Art No. RP-90P / GT146
Body  PP
Impellet and Vane PPS
Seal Material Viton
Screw and Nut A3
Mounting 2" Bung Adapter
Inlet / Outlet Dia  32mm / 25mm
Product Length 1270mm
Speed 70R / Min
Capacity 300cc / Stroke
Flowing 20L/Min
Suction / Lift 1.5m /5m
Applicable Drums       5, 15, 30, 55 Gallon
Applications Acid,alkali,alcohol,diesel fuel,gasoline, machine oil,water

 GT147 Rotary Barrel Pump RP-90R PPS Manual Rotary Drum Pump With 2" Bung
Art No RP-90R / GT147
Body,Impellet,Vane PPS
Other Parts PP
Seal Material F4
Screw and Nut 201SS
Mounting 2" Bung Adapter
Inlet / Outlet Dia  32mm / 25mm
Product Length 1270mm
Speed 70R / Min
Capacity 300cc/Stroke
Flowing 20L/Min
Suction / Lift 1.5m /5m
Applicable Drums 5, 15, 30, 55 Gallon
Applications Acid,alkali,alcohol,diesel fuel,gasoline, machine oil,water

 GT148 Rotary Hand Pump RP-90RT PTFE Manual Rotary Drum Barrel Pump
Art No. RP-90RT / GT148
Body PPS
Shrank Hand PP
Seal Material F4
Screw and Nut 201SS
Outlet tube 201SS
Mounting 2" Bung Adapter
Inlet / Outlet Dia  32mm / 25mm
Product Length 1270mm
Speed 70R / Min
Capacity 300cc/Stroke
Flowing 20L/Min
Suction / Lift 1.5m /5m
Applicable Drums 5, 15, 30, 55 Gallon
Applications Acid,alkali,alcohol,diesel fuel,gasoline, machine

  Rotary Hand Drum Pump Adblue - PP 25mm 21L/Min
Art No.                  GT145
Body PP
Impellet and Vane PPS
Seal Material Viton
Screw and Nut 304SS
Mounting 2" Bung Adapter
Inlet / Outlet Dia  27mm / 25mm
Product Length 1280mm
Speed 70R / Min
Capacity 300cc / Stroke
Flowing 21L/Min
Suction / Lift 3m /5m
Applicable Drums 15, 30, 55 Gallon
Packing 1PC/BOX,10PCS/CTN
N/G Weight 17/18KGS
Carton Size 80 x 38 x 38cm
Applications Acid, alkali, gasoline, diesel, water, toluene, urea solution
Specifications︰Polypropylene ( PP ) Air-operated Fulid Oil Transfer Drum Pump

Materials: PP

Pipe Qty: 1 Piece

Suction Tube Length: 98CM

Overall Length: 130CM

Inlet/Outlet Dia: 43mm/22mm

Flow Rate: 190ML/Stroke

Max Flow GPM: 8(water)

Max Pressure: 100PSI

Specification:Fits 5 to 55 gallon drums

Application(s): For AdBlue/DEF, water, alcohol, gasoline, diesel, kerosene, lubricant, water based chemical acid and alkali solutions
Product Image

Air driven fuel fluid chemicals dispensing pump for 50 to 205 litre drums
Air driven fuel fluid chemicals dispensing pump for 50 to 205 litre drums

Transfer Refilling Gasoline Diesel Fuel Foot Pump Kit & Manual Nozzle w/ 6' Hose
Transfer Refilling Gasoline Diesel Fuel Foot Pump Kit & Manual Nozzle w/ 6' Hose

9L Vacuum Oil / Fluid Extractor / Syphon Manual Fuel / Coolant / Water
9L Vacuum Oil / Fluid Extractor / Syphon Manual Fuel / Coolant / Water

Aluminum 5 Gallon Tire Sealant Hand Pump
Aluminum 5 Gallon Tire Sealant Hand Pump

D-490 Lever Action Barrel Drum Pump for Oil or Petroleum Products
D-490 Lever Action Barrel Drum Pump for Oil or Petroleum Products

P-490 Plastic lever drum pump viton seals and 201 stainless steel rod
P-490 Plastic lever drum pump viton seals and 201 stainless steel rod

Lever Action Polypropylene Piston Drum Pump with 304/316 Stainless Steel Rod  P-490S
Lever Action Polypropylene Piston Drum Pump with 304/316 Stainless Steel Rod P-490S

R-490S Lever action drum pump with ryton body / 316 stainless steel rod Poly / Propylene piston & spout
R-490S Lever action drum pump with ryton body / 316 stainless steel rod Poly / Propylene piston & spout

Lever Operated Barrel Pump Suits Adblue Thinners Solvents Hydraulic Oils
Lever Operated Barrel Pump Suits Adblue Thinners Solvents Hydraulic Oils

Cast Iron Rotary Hand Pump / Drum Dispensing Pump WS-25
Cast Iron Rotary Hand Pump / Drum Dispensing Pump WS-25

32mm Cast Iron Rotary Barrel Pump Self Priming Oil Fuel Hand Drum Suction Pumps JS-32
32mm Cast Iron Rotary Barrel Pump Self Priming Oil Fuel Hand Drum Suction Pumps JS-32

Nylon Chemical Siphon Pump With 2" BSP Male Adaptor
Nylon Chemical Siphon Pump With 2" BSP Male Adaptor

Nylon Non Sparking Plastic Drum Wrench
Nylon Non Sparking Plastic Drum Wrench

Drum Dispensing Pump for Aggressive Chemicals / Solvents
Drum Dispensing Pump for Aggressive Chemicals / Solvents

Related Products
Copper Nozzle/Fittings For Jiggle Siphon Hose Anti-static Shaker Syphon Pump - 1/2" 3/4" 1"
Copper Nozzle/Fittings For Jiggle Siphon Hose Anti-static Shaker Syphon Pump
US $ 0.88
Self Priming Jiggle Siphon Hose 6  Shaker Syphon Pump with Anti-Static Tubing
Self Priming Jiggle Siphon Hose 6' Shaker Syphon Pump with Anti-Static Tubing
US $ 2.12
Steel Lever Action Drum Pump for Oil or Petroleum Products
Steel Lever Action Drum Pump for Oil or Petroleum Products
US $ 7.15
Lever Action Barrel Diesel Oil Fuel Hand Transfer Pump 205L Drum
Lever Action Barrel Diesel Oil Fuel Hand Transfer Pump 205L Drum
US $ 11.55

Home  |  Product Catalog  |  E-mail  |  Documents  |  Contact Us  |  Hand & Drum Pump  |  Fluid Transfer Items  |  New Products  |  Plastic Funnel  |  PE Plastic Taps  |  Bilge Pumps  |  Jerry Cans  |  Sitemap  |  Mobile Version
  English     简体版     繁體版
Powered by DIYTrade.com
