150L/Min AC Electric Barrel Pump 316 Stainless Steel Chemical Drum Pump

150L/Min AC Electric Barrel Pump 316 Stainless Steel Chemical Drum Pump
Model No.︰GT1015
Brand Name︰OEM
Country of Origin︰China
Unit Price︰US $ 350 / PC
Minimum Order︰20 PC
Share on:

 Total 45 Related Items
Prev1617181920Next

Product Description

150L/Min AC Electric Barrel Pump 316 Stainless Steel Chemical Drum Pump

 304SS.jpg 304 Stainless Steel Electric Chemical Barrel Pump
Voltage 220V
Power 0.88KW
Material 304 Stainless Steel
Suction Tube  304 Stainless Steel
Seal Material Viton
Vane Material  304 Stainless Steel
Spout Material 304 Stainless Steel
Inlet/Out Dia 50mm/25mm
Tube Length 1000mm
Output Flowing 110L/Min
Suction/Lift 5m/7.5mm
Speed 10000R/Min
Fits on 15 - 55 Gallon Drums
Applications Acid,alkali,diesel,machine oil,water, toluene,Uric acid

Packing 2PCS/CTN
N/G Weight 14/15KGS
Carton Size 148 x 34 x 18cm

 316SS.jpg 316 Stainless Steel Electric Chemical Barrel Pump
Voltage 220V
Power 0.8KW
Material 316 Stainless Steel
Suction Tube  316 Stainless Steel
Seal Material Viton
Impeller Material  304 Stainless Steel
Spout Material 304 Stainless Steel
Inlet/Out Dia 42mm/25mm
Tube Length 1000mm
Output Flowing 150L/Min
Suction/Lift 5m/10mm
Motor Changable Speed
Max Viscosity 1200CPS
Fits on 15 - 55 Gallon Drums
Applications Acid,alkali,diesel,gasoline,machine oil,water,alcohol,toluene,Uric acid

Packing 2PCS/CTN
N/G Weight 19/20KGS
Carton Size 148 x 34 x 18cm

 12-250.jpg Electric Barrel Pump - 12/24V 420W 60L/Min
Material Aluminum Alloy
Total Length 1.2m
Motor Single-phase DC Morot
Voltage 12V/24V
Power 420W
Inlet Dia 44mm
Outlet Dia 25mm
Output Flowing 60L/Min
Suction 5m
Lift 10m
Cable 1.5m
Application Diesel,Kerosene,Water
Packing 1PC/BOX,10PCS/CTN
N/G Weight 31/33KGS
Carton Size 109 x 31 x 41cm

 13-250.jpg Electric Barrel Pump - 220V 420W 60L/Min
Material Aluminum Alloy
Total Length 1.2m
Motor Single-phase Motor
Voltage 220V
Power 420W
Inlet Dia 44mm
Outlet Dia 25mm
Output Flowing 60L/Min
Suction 5m
Lift 10m
Cable 1.5m
Application Diesel,Kerosene,Water
Packing 1PC/BOX,10PCS/CTN
N/G Weight 31/33KGS
Carton Size 109 x 31 x 41cm

 2-250.jpg 12V/24V Engine Oil Transfer Pump
Art No DC 12V/24V 100W Engine Oil Transfer Pump
Certificate CE
Theory Gear Pump
Voltage DC 12V/24V
Power 100W
No-Load Current 2.5A
Load Current 5A
Worke Cycle 30 Min
Flow 1-4L/Min
Inlet Tube 6mm x 800mm Copper Tube
8mmx1000mm PU Tube
Outlet Tube 10mmx1000mm PU Tube
Packing 12PCS/CTN
N.W/G.W 19.5/22KGS
Carton Size 54 x 42 x 31cm

 1-250.jpg 12V Diesel Heating Motor Oil Extractor Pump
Art No DC 12V 60W Engine Oil Transfer Pump
Maximum Current 5A
Maximum Power 60W
Sound Pressure Level 70dB(A)
Power Supply 12V- vehicle battery
Diesel/Heating Oil Flow Rate 250L/H
Motor oil (40-60 degrees) Flow Rate 1L/Min
Oil Extractor Pump Size 13 x 8 x 8.5cm ( L x W x H )
Input Hose 1.2m/6mm/4mm (Length/Outer Dia/Inner Dia)
Outlet Hose 1.5m/12mm/10mm (Length/Outer Dia/Inner Dia)
Packing 10PCS/CTN
N.W/G.W 9/10KGS
Carton Size 46.5 x 23 x 39.5cm

 3-250.jpg 220V Engine Oil Transfer Gear Pump Motor 550W 20L/Min
Art No AC 220V 550W 20L/Min
Certificate CE
Voltage AC 220-240V
Power 550W
Self-Priming Yes
Inlet/Outlet Dia 25mm/25mm
Cable Length 1.3M
Speed 1400R/Min
Flow 20L/Min
Suction/Lift 10m/20m
Packing 1UNIT/BOX,2UNITS/CTN
Net Weight 8.5KGS
N.W/G.W 17/18KGS
Carton Size 45 x 32 x 23cm
Applications #32,46,68 engine oil or Hydraulic oil

 5-250.jpg Electric 12V/24V AdBlue Liquid Transfer Membrane Pump
Certificate CE
Power 330W
Speed 3000R/Min
Flow 40L/Min
Pump Type Diaphragm
Housing Polyproplyene
Diaphragm TPU
Check Valve Viton
Check Valve Spring 316 Stainless Steel
Motor Shaft 316 Stainless Steel
Inlet/Outlet Dia 25mm
Maximum Working Pressure 40PSI ( 3 Bar )
Switch Setting Yes
Self Priming Up to 5M vertically
Liquid Temperature No more than 60°C
Applications AdBlue;Urea;Water

 6-250.jpg Electric AC Adblue Transfer Diaphragm Pump 220V 40L/Min
Certificate CE
Power 330W
Speed 2850R/Min
Flow 40L/Min
Pump Type Diaphragm
Housing Polyproplyene
Diaphragm TPU
Check Valve Viton
Check Valve Spring 316 Stainless Steel
Motor Shaft 316 Stainless Steel
Inlet/Outlet Dia 25mm
Maximum Working Pressure 40PSI ( 3 Bar )
Switch Setting Yes
Self Priming Up to 5M vertically
Liquid Temperature No more than 60°C
Applications Adblue;Urea;Water

 14-250.jpg Mini Submersible Diesel Fuel Transfer Pump - 51MM - 12V/24V
Pump Body Material Stainless Steel/Plastic/Aluminum
Motor Case,Impeller Plastic - PP
Filter,Outlet Plastic - Nylon
Stator Material Magnetic Steel
Seal Material NBR
Switch 6A - 250AC
Voltage 12V/24V
Power 60W
Outlet Dia 19mm
Cable  3m
Overall Size 50.8 x 50.8 x 177mm
Flow 30L/Min
Lift 3m
Speed 8500 R/Min
Self-Priming Yes
Applications Diesel,Kerosene,Water

 GT821 Stainless Steel-38MM.jpg Mini Submersible Diesel Fuel Transfer Pump - 38MM - 12V/24V
Pump Body Material Stainless Steel/Plastic/Aluminum
Motor Case,Impeller Plastic - PP
Filter,Outlet Plastic - Nylon
Stator Material Magnetic Steel
Seal Material NBR
Switch 6A - 250AC
Voltage 12V/24V
Power 40W
Outlet Dia 19mm
Cable  3m
Overall Size 38 x 38 x 117mm
Flow 20L/Min
Lift 2m
Speed 8500 R/Min
Self-Priming Yes
Applications Diesel,Kerosene,Water

 GT811-A.jpg Fuel Oil Diesel Transfer Pump - 45L/Min 175W DC 12V/24V
Art No DC 12V/24V 175W 45L/Min
Certificate CE
Voltage DC 12V/24V
Power 175W
Inlet/Outlet Dia 25mm/25mm
Impeller Shaft No.45 Powder Metallurgy
Flow 45L/Min
Suction/Lift 5m/10m
Net Weight 3.7KGS
Packing 1SET/BOX,6SET/CTN
N.W/G.W 23/24KGS
Carton Size 59 x 52 x 21cm
Applications Diesel,Kerosene

 GT811-B.jpg Diesel Fuel Oil Transfer Pump - 175W 45L/Min 12V/24V
Art No DC 12v/24v 175W 45L/Min
Certificate CE
Voltage DC 12V/24V
Power 175W
Inlet/Outlet Dia 25mm/25mm
Impeller Shaft Cast Iron
Flow 45L/Min
Suction/Lift 3m/7m
Packing 1SET/BOX,6SET/CTN
N.W/G.W 23/24KGS
Carton Size 59 x 52 x 21cm
Applications Diesel,Kerosene

 GT811-E.jpg Diesel Fuel Transfer Pump - 70L/Min 550W DC 12V/24V
Voltage DC 12V/24V
Power 550W
Inlet/Outlet Dia 25mm/25mm
Impeller Shaft No.45 Powder Metallurgy
Flow Rate 70L/Min
Suction 5m
Lift 10m
Packing 1SET/BOX,6SET/CTN
N.W/G.W 32/36KGS
Carton Size 54 x 27 x 39cm
Applications Diesel,Kerosene

 GT811-AC.jpg Diesel Fuel Transfer Pump - 60L/Min 550W AC 220-240V
Art No AC 220V 550W 60L/Min
Certificate CE
Voltage AC 220-240V
Power 550W
Frequency 50HZ
Inlet/Outlet Dia 25mm/25mm
Impeller Shaft No.45 Powder Metallurgy
Speed 2800R/Min
Flow 60L/Min
Suction/Lift 5m/10m
Packing 1UNIT/BOX,2UNITS/CTN
Net Weight 8.5KGS
N.W/G.W 17/18KGS
Carton Size 45 x 32 x 23cm
Applications Diesel,Kerosene
Specifications︰150L/Min AC Electric Barrel Pump 316 Stainless Steel Chemical Drum Pump
Product Image

150L/Min AC Electric Barrel Pump 316 Stainless Steel Chemical Drum Pump
150L/Min AC Electric Barrel Pump 316 Stainless Steel Chemical Drum Pump
